Optimal for professional forestry, orchards of all kinds
180 mm Diameter Capacity branches and logs can be chipped
Wooden blocks of 180mm x 300mm can also be chipped.
Hydraulically fed hopper with Intelligent Electronic Feeding Device
| Drive System: | Direct Drive, PTO with Shearbolt |
| KW (HP) Range: | 30- 75 Kw (40 – 100 HP) |
| Chipper Capacity: | 180 mm | Rotor Size: | 71,1 cm |
| Knife Type: | Hardened Tool Steel |
| Dimensions LxWxH (Hopper Folded): | 211 x 142 x 229 (cm) |
| Discharge Hood Rotation: | 285 degrees |
| Discharge Hood Height: | 2286 mm |
| KW Requirements for Maximum Capacity: | 55-65kW (60 – 70 HP) |
| Recommended Hydraulic Flow: | 3 - 6 GPM (11 – 25 LPM) |
| Chipper Housing Opening: | 180 x 280 mm |
| Number of Rotor Knives: | 4 Segmented |
| Rotor Weight: | 83,9 kg |
| Hopper Opening: | 66,0 x 88,9 cm |
| Rated RPM: | 540 - 1000 |
| Weight: | 590 kg |
Grizzly BXR Wood Chippers have a PTO powered rotor and hydraulic feed hopper, meaning branches, limbs and brush are control fed for continuous chipping at maximum capacity.
The Grizzly 180 Wood Chipper from Scanwood Solutions comes standard with a three point hitch, hydraulic operated feed rollers and is ideal for tractors with a kw rating of between 45 – 55 kw. The slab style opening of the Grizzly 180 leads to an impressive chipping capacity. While it is a 180mm chipper, the 300mm horizontal opening lets you feed the chipper with a lot more than you would expect. The chipping capacity is also due to the 72cm steel rotor weighing 85kg and comes standard with 4 hardened tool grade steel knives. Behind each knife is the manufacturer’s, Wallenstein equipment, twig breaker system which virtually eliminates clogging. The Scanwood Grizzly 180 Wood Chipper also comes standard with two hydraulically operated feed rollers which grab hold of branches and aggressively pulls them into the wood chipper. The Grizzly 180 Control bar meets the most recent and stringent safety global standards. It features two stop positions as well as forward and reverse functionality. The Grizzly 180 features Intelligent Electronic Feeding Device (IEFD) which continually match feed and rotor speed for fewer stops. The Grizzly 180 Wood Chipper, proudly manufactured in Canada, comes standard with a 5 year warranty on build quality.
In terms of safety the machine complies with current regulations in the EU. The wood chipper is equipped with an operation bar for controlling the feed roller. With the operation bar it is possible for the operator to start and stop as well as reverse of the feed roller.
